Konnect

Overview


A series of IoT connectivity devices for remote monitoring and control of your machines or equipment using GPS, GSM/GPRS, Wi-Fi, LORA, and Bluetooth. Crevavi Konnect can be retrofit on already installed equipment which are to be remotely monitored.

Customized Business logic can be built to Crevavi Konnect based on the application requirement with the On-board microcontroller. Crevavi Konnect is very useful in a very wide range of applications including Solar, Retail, UPS and Vending machine remote monitoring requirements

Utilization of Konnect is limitless.. for automotive telematics, Industrial/Medical equipment monitoring, Solar Projects, Power Equipment Monitoring, Electronics Cash register/Vending Machines for Transaction Monitoring, etc.

Products in this series (not limited to)

  • Konnect-Wi – Wi-Fi Based
  • Konnect-B – GSM/GPRS Based
  • Konnect-G – GSM/GPRS with GPS
  • Konnect-SCAN – GSM/GPRS with GPS and CAN
  • Konnect-L – LORA Based






Functionality


  • Connect to Local server through Wi-Fi, or remote server through mobile network
  • Downstream connectivity through CAN, RS232, Modbus, Bluetooth, or USB with smart devices
  • Integrate Digital and Analog sensors
  • Digital outputs to control relays / switches
  • Battery backed power (Li-ion charger inbuilt)
  • Mobile app to monitor and control
  • schedule periodical response, or responds to command from server
  • Programmable, to support various needs of business logics

User Benefit


  • IoT using cellular network eliminates the need to have broadband connection at site
  • Business Logic can be customized on on-board microcontroller, reduce bandwidth /tariff costs
  • Cost-optimize field service operations, personnel and fleet expenses
  • Reduces down-time, make informed decisions by deploying analytics of collected data
  • predictive maintenance of the equipment



Gallery


Crevavi Konnect – IoT Products

Konnect-Wi IoT Capability Demo

Konnect Hardware Variations




Downloads


CRE0006BRO1746-0V1 Konnect Brochure
CRE0006PRE1752-0V1 IoT Success Stories
CRE0023MAN1749-1V1 Konnect-Wi Quick Reference Guide






Specifications


Item Konnect-Wi Konnect-B Konnect-G Konnect-SCAN Konnect-LORA
Upstream COM Wi-Fi GPRS GPRS, Bluetooth GPRS, Bluetooth LORA
GPS × × Optional
COM Modem ESP8266 Simcom SIM900A Quectel MC60 Simcom SIM868 Semtech
Core Arm Cortex M0 AVR 8Bit Arm Cortex M0 Arm Cortex M0 Arm Cortex M0
Processor Speed 48MHz 32MHz 48MHz 48MHz 48MHz
On-chip Flash 64KB 32KB 256KB 256KB 32KB
On-Chip RAM 8KB 4KB 32KB 8KB 8KB
Storage Memory No EEPROM 128Bytes SD Card Serial EEPROM 2MB Serial EEPROM 2MB
Downstream COM RS232/MODBUS RS232/MODBUS RS232/MODBUS, Bluetooth CAN, RS232/MODBUS CAN, RS232/MODBUS
GPIO/Analog √ Dedicated 8-In, 2-Out
Protocol Support TCP, HTTPS, MQTT< TCP, HTTPS, MQTT TCP, MQTT TCP, MQTT TCP, MQTT
Temperature -25 to 85 Deg -25 to 85 Deg -25 to 85 Deg -25 to 85 Deg -25 to 85 Deg
Input Power 9-28VDC 9-28VDC 9-28VDC 9-28VDC 9-28VDC
Diamension 105x75x25mm 95x70x25mm 70x50x20mm 70x55x20mm 70x55x20mm
